5-18 Determining Basic Drive Configuration SYNAX200
DOK-SYNAX*-SY*-07VRS**-PR01-EN-P
Usable Motors DIAX04:
• MHD
• MKD
• MKE
• 2AD with HSF
• ADF with HSF
Basic Drive Configuration HS12 (DIAX04):
pos. travel range limit switch
neg. travel range limit switch
scale input
U1 (DSS)
SY7PR096.FH7
MHD
MKD
MKE
2AD
ADF
reference switch
slide
Read and follow
Instructions for Electrical Drives"
manual,
DOK-GENERL-DRIVE******-SVS...
DANG
High oltage.
Danger of electrical shock.
Donot touch electrical connections
fo
5 minutes after switching
LWL
IKS4374
Fig. 5-22: Drive with MHD, MKD, MKE, 2AD or ADF motor with DSF and indirect
position detection
MHD, MKD, MKE, 2AD with HSF,
ADF with HSF
