5-24 Determining Basic Drive Configuration SYNAX200
DOK-SYNAX*-SY*-07VRS**-PR01-EN-P
Usable Motors DIAX04:
• LAF
• LAR
• LSF
Basic Drive Configuration HS32 (DIAX04):
pos. travel range limit switch
neg. travel range limit switch
scale input
reference switch
Read and follow
Instructions for Electrical Drives"
manual,
DOK-GENERL-DRIVE******-SVS...
DANG
High oltage.
Danger of electrical shock.
Do not touch electrical connections
fo
5 minutes after switching
LWL
U2 (DLF)
U1 (DSS)
incremental
linear scale with
sine output
linear motor
LAR
LAF
LSF
SY7PR099.FH7
Fig. 5-28: Drive with linear motor LAR, LAF or LSF and incremental position
detection
LAR, LAF, LSF:
