Ricoh D129 - Browser Unit Type I; Installation Procedure

Browser Unit Type I
SM 2-83 D129/D130
Installation
2.22 BROWSER UNIT TYPE I
2.22.1 INSTALLATION PROCEDURE
Use the following procedure to install the Browser Unit Type I.
1. Turn the main switch ON.
2. Press the “User Tools/Counter” key.
3. On the touch panel, press “System Settings”.
4. Make sure that the “Increase Scanner Memory by Disabling Browser” setting in the
General Features tab is OFF.
5. Turn the main switch OFF.
6. Remove the control cover [A] (screws x 2).
7. Insert the Browser Option SD card in the lower slot [A].
8. Turn the main switch ON.
9. Touch the “User Tools/Counter” key.
Rev. 04/20/2012
⇒
