Transfer
D129/D130 4-50 SM
4.8 TRANSFER
4.8.1 TRANSFER BELT UNIT
 To avoid exposing the drum to strong light, cover it with paper if the right cover will be
open for a long period.
1. Open the right door [A].
2. Release the lever [B].
3. Transfer belt unit [C]
 Avoid touching the transfer belt surface.
