Internal Shift Tray (D633)
D129/D130 2-62 SM
2.15 INTERNAL SHIFT TRAY (D633)
2.15.1 COMPONENT CHECK
Check the quantity and condition of the components against the following list.
No. Description Q’ty
1 Shift Tray Unit 1
2 Paper Guide - Small 2
3 Connector Cover 1
2.15.2 INSTALLATION PROCEDURE
 Unplug the copier power cord before starting the following procedure.
1. Remove all tapes.
2. Remove the standard tray [A].
