Main SP Tables-9
SM 5-183 D129/D130
Service
Tables
5.11 MAIN SP TABLES-9
5.11.1 INPUT CHECK TABLE
When entering the Input Check mode, 8 digits display the result for a section. Each digit
corresponds to a different device as shown in the table.
Bit No. 7 6 5 4 3 2 1 0
Result 0 or 1 0 or 1 0 or 1 0 or 1 0 or 1 0 or 1 0 or 1 0 or 1
Copier
5803
Input Check
Description
Reading
0 1
001
Tray 1: Paper Size Sensor See the table 1 following this table.
002
Tray 1: Tray Set Sensor Set Not set
003
Tray 1: Paper Lift Sensor Not upper limit Upper limit
004
Tray 1: Paper End Sensor No paper Paper remaining
005
Tray 1:
Paper Height Sensor 1
See the table 2 following this table.
006
Tray 1:
Paper Height Sensor 2
007
Tray 2: Paper Size Sensor See the table 1 following this table.
008
Tray 2: Tray Set Sensor Set Not set
009
Tray 2: Paper Lift Sensor Not upper limit Upper limit
010
Tray 2: Paper End Sensor No paper Paper remaining
