Ricoh D129 - Installation Procedure; Preliminary Procedures

Main Machine Installation
SM 2-7 D129/D130
Installation
Description Q'ty
38
CD-ROM: Operation Instruction - App 2 Me
(-57, -58, -67, -69, -59)
1
39
Quick Reference Guide - App 2 Me
(-57, -58, -69, -59)
1
40 Quick Reference Guide – Start Up (-27, -67) 1
41 Sheet – Notes – Manual – CD (-19, -59, -21, -61) 1
2.3.2 INSTALLATION PROCEDURE
Preliminary Procedures
Put the machine on the paper feed unit or the LCT first if you will install an optional paper feed
unit or the optional LCT at the same time. Then install the machine and other options.
 Keep the shipping retainers after you install the machine. You may need them in the
future if you transport the machine to another location.
1. Remove all the tapes and retainers on the machine.
2. Remove all the tapes and retainers in trays 1 and 2, and then take out the power cord from
tray 1 (if applicable).
