Main SP Tables-6
D129/D130 5-108 SM
5.8 MAIN SP TABLES-6
5.8.1 SP6-XXX: PERIPHERALS
6006*
ADF Registration Adjust
Adjusts the side-to-side and leading edge registration for simplex and
duplex original feeding in ARDF mode.
SP6006-5 sets the maximum setting allowed for rear edge erase.
001 Side-to-Side Regist: Front
[–3 to 3 / 0 / 0.1 mm / step]
002 Side-to-Side Regist: Rear
003 Leading Edge Registration [–5 to 5 / 0 / 0.1 mm / step]
005 Buckle: Duplex Front [–3 to 3 / 0 / 0.1 mm / step]
006 Buckle: Duplex Rear [–2.5 to 2.5 / 0 / 0.1 mm / step]
007 Rear Edge Erase [–10 to 10 / 0 / 0.1 mm / step]
6007 ADF Input Check
001
Original Length 1 (B5 Detection
Sensor)
0: Paper not detected
1: Paper detected
002
Original Length 2 (A4 Detection
Sensor)
003
Original Length 3 (LG
Detection Sensor)
004 Original Width Sensor 1
005 Original Width Sensor 2
006 Original Width Sensor 3
007 Original Width Sensor 4
008 Original Width Sensor 5
