Main SP Tables-4
D129/D130 5-24 SM
4417
IPU Test Pattern
Selects the IPU test Pattern.
Test
Pattern
[0 to 28 / 0 / 1]
0: Scanned image 15: Gray pattern (1)
1: Gradation main scan A 16: Gray pattern (2)
2: Gradation main scan B 17: Gray pattern (3)
3: Gradation main scan C 18: Shading pattern
4: Gradation main scan D 19: Thin line pattern
5: Gradation sub scan (1) 20: Scanned + Grid pattern
6: Grid pattern (1) 21: Scanned + Gray scale
7: Slant grid pattern 22: Scanned + Color patch
8: Gradation K 23: Scanned + Slant Grid C
9: Gray patch 16 24: Scanned + Slant Grid D
10: Gray patch 16 (1) 25: Gray Scale 18 text
11: Gray patch 16 (2) 26: Gray Scale 18 photo
12: Gray patch 64 27: Gray Scale 256 text
13: Grid pattern (2) 28: Gray Scale 256 photo
14: Color patch K
4429* Select Copy Data Security
001
Copying
Adjusts the density of the embedded message
with the copy data security unit.
[0 to 3 / 3 / 1 ]
3: Darkest density
002
Scanning
003
Fax Operation
