Main SP Tables-5
D129/D130 5-58 SM
5802*
FreeRun
Performs a free run on the copier engine.
The correct paper should be loaded in the 1st tray or 2nd tray, but paper is
not fed.
The main switch has to be turned off and on after using the free run mode
for a test.
001 TRAY1:A4LEF -
002 TRAY2:A3 -
003 TRAY2:A4SEF -
5803
Input Check
Displays the signals received from sensors and switches. ( "Input Check
Table" in "Main SP Tables-9")
5804
Output Check
Turns on the electrical components individually for test purposes. (
"Output Check Table" in "Main SP Tables-9")
5805
Anti-Condensation Heater
[0 or 1 / 0 / -]
0:OFF / 1:ON
5810 SC Reset
001 Fusing SC Reset
Resets all level A service call conditions, such as
fusing errors. To clear the service call, touch
"Execute" on the LCD, then turn the main power
switch off/on.
