Main SP Tables-5
D129/D130 5-82 SM
011
WEP Key Select
Selects the WEP key.
Bit 1 and 0
00: Key1, 01: Key2 (Reserved),
10: Key3 (Reserved), 11: Key4(Reserved)
This SP is displayed only when the IEEE802.11 card is installed.
013
RTS/CTS Thresh
Adjusts the RTS/CTS threshold for the IEEE802.11 card.
[0 to 3000 / 2432 / 1]
This SP is displayed only when the IEEE802.11 card is installed.
042
Fragment Thresh
Adjusts the fragment threshold for the IEEE802.11 card.
[256 to 2346 / 2346 / 1]
This SP is displayed only when the IEEE802.11 card is installed.
043
11g CTS to Self
Determines whether the CTS self function is turned on or off.
[0 to 1 / 1 / 1] 0: Off, 1: On
This SP is displayed only when the IEEE802.11 card is installed.
044
11g Slot Time
Selects the slot time for IEEE802.11.
[0 to 1 / 0 / 1] 0: 20
m, 1: 9 m
This SP is displayed only when the IEEE802.11 card is installed.
045
WPA Debug Lvl
Selects the debug level for WPA authentication application.
[1 to 3 / 3 / 1] 1: Info, 2: warning, 3: error
This SP is displayed only when the IEEE802.11 card is installed.
