Select "3 SD Card" to save the debug information directly to the SD card if it is
inserted in Slot 2 (Lower Slot).
5. Now touch "5858" and specify the events that you want to record in the debug log. SP5858
(Debug Save When) provides the following items for selection.
1 Engine SC Error
Saves data when an engine-related SC code is
generated.
2 Controller SC Error
Saves debug data when a controller-related SC Code
is generated.
3 Any SC Error
Saves data only for the SC code that you specify by
entering code number.
4 Jam Saves data for jams.
More than one event can be selected.
Example 1: To Select Items 1, 2, 4
Touch the appropriate items(s). Press "ON" for each selection. This example shows
"Engine SC Error" selected.
Example 2: To Specify an SC Code
Touch "3 Any SC Error", enter the 3-digit SC code number with the control panel number
keys, then press
. This example shows an entry for SC670.
