Ricoh D129 - Page 609

System SP Table-1
SM Appendix 3-5 D129/D130
Appendix:
Service
Program
Mode Tables
001
Roller Center
C1b/C1.5b: [100 to 170 / 140 / 1 deg]
C1c/C1.5c: [100 to 170 / 150 / 1 deg]
Adjusts the fusing temperature at the center of the hot roller.
002
Roller Ends
C1b/C1.5b: [100 to 170 / 145 / 1 deg]
C1c/C1.5c: [100 to 170 / 155 / 1 deg]
Adjusts the fusing temperature at the ends of the hot roller.
003
Re-load Temp. Minus: Roller Center [0 to 60 / 0 / 1 deg]
Sets the reload temperature for the center of the hot roller. This setting
depends on the target temperature.
Reload temp. = Target Temp – This SP Setting
 Do not set a temperature that is higher than the setting for SP1105 1
(Roller Center: Trays)
004
Re-load Temp. Minus: Roller Ends [0 to 60 / 0 / 1 deg]
Sets the reload temperature for the ends of the hot roller. This setting depends
on the target temperature.
Reload temp. = Target Temp – This SP Setting
 Do not set a temperature that is higher than the setting for SP1105 2
(Roller Ends: Trays)
005 to
022
The following SPs adjust the fusing temperature at the center or ends of the
hot roller for each paper type.
005
Roller Center: M-Thick
C1b/C1.5b: [100 to 170 / 145 / 1 deg]
C1c/C1.5c: [100 to 170 / 155 / 1 deg]
006
Roller Ends: M-Thick
C1b/C1.5b: [100 to 170 / 150 / 1 deg]
C1c/C1.5c: [100 to 170 / 160 / 1 deg]
007
Roller Center: Thick 1
[100 to 170 / 130 / 1 deg]
008
Roller Ends: Thick 1
009
Roller Center: Thick 2
[100 to 170 / 150/ 1 deg]
010
Roller Ends: Thick 2
