Ricoh D158 - Exposure Lamp; Sio Board

Scanner Unit (D158/D159)
D158/D159/D160/D161/D170 4-23 SM
Replacement
and
Adjustment
4.4.3 SIO BOARD
1. Rear cover ( p.4-4)
2. SIO board with bracket [A] (
x 1, x 6)
4.4.4 EXPOSURE LAMP
1. Exposure glass ( p.4-20 "Exposure Glass/DF Exposure Glass (CCD)")
2. Move the exposure lamp [A] to the point shown below.
3. Exposure lamp [A] (
x 2, FFC x 1)
