Ricoh D158 - Feed Clutch

Original Feed Drive
SM 15 D724
ARDF
DF2030
(D724)
1.4.4 FEED CLUTCH
1. Rear cover ( p.1 "Rear Cover")
2. Harness guide (
p.13 "Pick-up Solenoid")
3. Bracket [A] (
x 2, x 3, x 1, bushing x 1, spring x 1)
4. Slide the bracket.
5. Feed clutch [B] (
x 1)
