Main SP Tables-6
D158/D159/D160/D161/D170 3-188 SM Appendix
3.6 MAIN SP TABLES-6
3.6.1 SP6-XXX (PERIPHERALS)
6006
[ADF Adjustment] (D158/159)
Adjusts the side-to-side and leading edge registration for simplex and duplex
original feeding in ARDF mode. SP6006-5 sets the maximum setting allowed for
rear edge erase.
001 Side-to-Side Regist: Front *ENG
[-3.0 to 3.0 / 0.0 / 0.1 mm / step]
002 Side-to-Side Regist: Rear *ENG
[-3.0 to 3.0 / 0.0 / 0.1 mm / step]
003 Leading Edge Registration *ENG
[-5.0 to 5.0 / 0.0 / 0.1 mm / step]
005 Buckle: Duplex Front *ENG
[-5.0 to 5.0 / 0.0 / 0.1 mm / step]
006 Buckle: Duplex Rear *ENG
[-5.0 to 5.0 / 0.0 / 0.1 mm / step]
007 Rear Edge Erase *ENG
[-10.0 to 10.0 / 0.0 / 0.1 mm / step]
6006
[ADF Adjustment] (D160/D161/D170)
-
001
StoS Regist *ENG
[-3.0 to 3.0 / 0.0 / 0.1 mm / step]
Adjusts the side-to-side registration for the front side of the original, for ARDF
mode.
002
Leading Regist *ENG
[-5.0 to 5.0 / 0.0 / 0.1 mm / step]
Adjusts the leading edge registration for both front and rear.
003
Rear Edge Erase *ENG
[-5.0 to 5.0 / 0.0 / 0.1 mm / step]
Adjusts the trailing edge erase margin for ARDF mode.
005
Magnification *ENG
[-5.0 to 5.0 / 0.0 / 0.1 % / step]
Adjusts the sub-scan magnification for the ARDF.
006 Buckle: Front *ENG
[-5.0 to 5.0 / 0.0 / 0.1 mm / step]
