Ricoh D158 - Paper Size Sensors; Tray Main Board

Sensors and Board
D698 8 SM
1.3.2 PAPER SIZE SENSORS
1. Pull out the tray.
2. Sensor bracket cover [A] ( x 1)
3. Sensor bracket [B] (
x 3, x 2)
4. Paper size sensor (hooks)
1.3.3 TRAY MAIN BOARD
1. Rear cover ( p.1 "Covers")
2. Tray main board [A] (All
s, x 4)
