Tables
Input Check Table for Copier (D158/D159)
-Conducting an Input Check -
1. Select SP5-803.
2. Select the number (see the table below) corresponding to the component.
3. Select "Execute." The copy mode is activated.
4. Either "01H" or "00H" appears (see the table below).
Num. Sensor/Switch 00H 01H
001 Tray 1: Paper Size Sensor *1: See “Table 1” *1: See “Table 1”
002 Tray 2: Paper Size Sensor *1: See “Table 1” *1: See “Table 1”
003 Tray 1: Tray Set Sensor Installed Not installed
004 Tray 2: Tray Set Sensor Installed Not installed
009 Tray 1: Paper End Sensor Paper detected Paper end
010 Tray 2: Paper End Sensor Paper detected Paper end
011 Tray 1:Paper Lift Sensor Not at upper limit At upper limit
012 Tray 2: Paper Lift Sensor Not at upper limit At upper limit
015 By-pass: Paper Size Sensor *1: See “Table 1” *1: See “Table 1”
016 By-pass: Paper End Sensor Paper detected Paper end
017 By-pass: Paper Length Sensor Paper detected Not detected
018 By-pass: Home Position Sensor Lowered Lifted
019 Paper Exit Sensor Paper detected Not detected
020 Paper Feed Sensor 1 Paper detected Not detected
021 Paper Feed Sensor 2 Paper detected Not detected
022 Registration Sensor Paper detected Not detected
023 Interchange Sensor Paper detected Not detected
024 Duplex: Exit Sensor Paper detected Not detected
025 Duplex: Entrance Sensor Paper detected Not detected
