Using SP Modes
D158/D159/D160/D161/D170 6-24 SM
Num. Sensor/Switch 00H 01H
027 Front Safety Sw - 24V Front door: Open Front door: Closed
029 Right Cover Open Right door: Closed Right door: Open
030 Duplex Fan Lock Locked Not locked
033 Fan Lock Locked Not locked
035 Main Motor Lock Locked Not locked
037 PCU Set Not set Set
039 Key Card Set Set Not set
040 Mechanical Counter Set Not set Set
041 Key Counter Set *2: See “Table 2” *2: See “Table 2”
042 BICU Version *2: See “Table 2”
043 VFEEDCOVER Closed Open
071 Bank: CPU-Port 2 *3: See “Table 3” *3: See “Table 3”
072 Bank: CPU-Port 3 *3: See “Table 3” *3: See “Table 3”
073 Bank: CPU-Port A *3: See “Table 3” *3: See “Table 3”
074 Bank: CPU-Port B *3: See “Table 3” *3: See “Table 3”
200 HP Sensor Not home position Home position
201 Platen Cover Sensor Open Closed
