Ricoh D158 - Firmware Update Procedure; Installation Procedure; VM Card (D158;D159)

Controller Options
D158/D159/D160/D161/D170 2-80 SM
2.15.3 VM CARD (D158/D159)
Installation Procedure
 Unplug the main machine power cord before you do the following procedure.
1. Remove the card slot cover [A] (
x 1).
2. Insert the SD card into slot 2 [B].
3. Reattach the card slot cover.
4. Turn the main switch on.
5. On the operation panel, remove the bottom blank keytop and replace it with the keytop
provided.
6. Attach the decal to the machine.
Firmware Update Procedure
Application halt
1. Press the “User Tools/Counter” key, then touch “Extended Feature Settings” twice on the LCD.
If required, log in as a machine administrator.
2. Press “Administrator Tools”, then press “Heap/Stack Size Settings”. Take note of the heap
size and stack size. (After updating, the heap and stack size settings are cleared.)
