Ricoh D158 - Hot Roller; Hot Roller Stripper Pawls

Fusing
D158/D159/D160/D161/D170 4-82 SM
4.11.4 HOT ROLLER STRIPPER PAWLS
1. Hot roller section ( p.4-81 "Fusing Lamps")
2. Roller guard [A] (
x 3)
3. Metal holders [B] (1 holder for each)
4. Hot roller stripper pawls [C] (1 spring for each)
4.11.5 HOT ROLLER
1. Hot roller stripper pawls ( p.4-82)
2. Hot roller [A] (2 C-rings, 1 gear, 2 bearings)
