Ricoh D158 - Ardf (D684)

Optional Equipment
D158/D159/D160/D161/D170 1-20 SM Appendix
1.4.2 ARDF (D684)
Original Size:
Standard sizes (Single-sided mode only):
A3 to B6, 11" x 17" to 5
1
/
2
" x 8
1
/
2
"
Non-standard sizes (Single-sided mode only):
Max. width 297 mm
Min. width 128 mm
Max. length 1,260 mm
Min. length 128 mm
Original Weight: 52 – 105 g/m
2
(14 – 28 lb)
Table Capacity: 100 sheets (81.4 g/m
2
, 22 lb)
Original Standard Position: Rear left corner
Separation: RF
Original Transport: Roller transport
Original Feed Order: From the top original
Reproduction Range: 50 – 200%
Power Source: 24 and 5 Vdc (from the mainframe)
Power Consumption: 42 W
Dimensions (W x D x H): 565 x 500 x 125 mm (22.4" x 19.6 x 4.9")
Weight: Not more than 8.2 kg (18 lb)
