Ricoh D158 - Paper Jam Counters (Sp 7504)

Using SP Modes
D158/D159/D160/D161/D170 6-35 SM
Service
Tables
6.4.8 PAPER JAM COUNTERS (SP 7504)
The table lists the menu numbers (the last three digits of SP7-504-XXX) and the paper jam
timings and locations.
Code Timing and Locations (D160/D161/D170)
001 At Power On
010 Off-Regist NoFeed
011 Off-1 Vertical SN
012 On-1 Vertical SN
021 Off-2 Vertical SN
022 On-2 Vertical SN
031 Off-3 Vertical SN
032 On-3 Vertical SN
050 Off-Regist Bypass
060 Off-Regist Duplex
070 On-Regist SN
120 On-Exit SN
121 Off-Exit SN
122 On-Exit SN
123 Off-Dup Inverter
125 On-Dup Inverter
126 Off-Dup Entrance
127 On-Dup Entrance
128 Off-Duplex Exit
129 On-Duplex Exit
