Using SP Modes
D158/D159/D160/D161/D170 6-20 SM
Num. Sensor/Switch 00H 01H
060 Bypass: HP Not lifted Lifted
061 Key Card Install Not installed Installed
071 Bank: CPU-Port2 *3
072 Bank: CPU-Port3 *3
073 Bank: CPU-PortA *3
074 Bank: CPU-PortB *3
080 ADF Lift Up Closed Open
081 ADF Feed Cover Closed Open
082 ADF Original Set Not detected Paper detected
083 ADF Registration Not detected Paper detected
084 ADF Exit Sensor Not detected Paper detected
085 ADF Rear Edge Not detected Paper detected
086 ADF Org Length1 *4
087 ADF Org Length2 *4
088 ADF Org Length3 *4
089 ADF Org Width1 *4
090 ADF Org Width2 *4
091 ADF Org Width3 *4
092 ADF Org Width4 *4
093 ADF Skew Correct Not detected Paper detected
