Main SP Tables-4
D158/D159/D160/D161/D170 3-54 SM Appendix
4600
[SBU Version Display] (D158/D159)
-
001 SBU ID ENG
[0x00 to 0xFF / 0 / 1/ step]
002 SCAT ID ENG
[0x00 to 0xFF / 0 / 1 / step]
4602
[Scanner Memory Access] (D158/D159)
Enables the read and write check for the SBU registers.
001 Scanner Memory Access ENG
[0x00000000 to 0xFFFFFFFF /
0x00000000 / - / step]
4603
[Auto Adjustment Operation] (D158/D159)
Executes the AGC and enables the home position detection.
001 HP Detection Enable ENG
[0 or 1 / 0 / 1 / step]
002 HP Detection Disable ENG
[0 or 1 / 0 / 1/ step]
4603
[Force AGC] (D160/D161/D170)
-
001 Force AGC ENG
[0 or 1 / 0 / 1/ step]
4604
[FGATE Open/Close] (D158/D159)
Opens or closes the FGATE
001 FGATE Open/Close ENG
[0 or 1 / 0 / 1 / step]
0:OFF, 1:ON
