Main SP Tables-5
SM Appendix 3-185 D158/D159/D160/D161/D170
Service
Program
Mode Tables
5985
[Device Setting] (D158/159)
Enables/disables the on-board device.
001
On Board NIC CTL
[0 to 2 / 0 / 1/step]
0: Disable, 1: Enable,
2: Function limitation
When the "Function limitation" is set, "On board NIC" is limited only for the
NRS or LDAP/NT authentication.
Other network applications than NRS or LDAP/NT authentication are
not available when this SP is set to "2".Even though you can change
the initial settings of those network applications, the settings do not
work.
002
On Board USB CTL
[0 or 1 / 0 / 1/step]
0: Disable, 1: Enable
5987
[Mech. Counter]
This SP detects that a mechanical counter device is removed. If it is detected,
SC610 occurs.
001
0: OFF:, 1: ON: *ENG
[0 or 1 / 0 / 1/step]
5990
[SP Print Mode] (D158/159)
[SMC Print] (D160/D161/D170)
Prints out the SMC sheets.
001
All(Data List)
(All)
CTL
Press “Execute” key to start printing
the SMC sheets.
[- / - / -]
[Execute]
002
SP(Mode Data List)
(SP)
CTL
003 User Program CTL
004 Logging Data CTL
