Ricoh D158 - Page 697

System SP Tables-8
SM Appendix 3-239 D158/D159/D160/D161/D170
Appendix:
Service
Program
Mode Tables
8681
T:PCFAX TXPGS
(D158/D159)
*CTL
These SPs count the number of pages
sent by PC Fax. These SPs are provided
for the Fax application only, so the counts
for SP8681 and SP8683 are the same.
[0 to 9999999 / 0 / 1]
8683
F:PCFAX TXPGS
(D158/D159)
*CTL
 This counts pages sent from a PC using a PC fax application, from the PC through the copier
to the destination.
 When sending the same message to more than one place using broadcasting, the pages are
only counted once. (For example, a 10-page fax is sent to location A and location B. The
counter goes up by 10, not 20.)
8701
TX PGS/Port (D158/D159)
These SPs count the number of pages sent by the physical port used to send
them. For example, if a 3-page original is sent to 4 destinations via ISDN G4,
the count for ISDN (G3, G4) is 12.
001 PSTN-1 *CTL
[0 to 9999999 / 0 / 1]
002 PSTN-2 *CTL
003 PSTN-3 *CTL
004 ISDN (G3,G4) *CTL
005 Network *CTL
8711
T:Scan PGS/Comp (D158/D159)
These SPs count
the number of compressed pages scanned into the document
server, counted by the formats listed below.
001
JPEG/JPEG2000 *CTL
[0 to 9999999 / 0 / 1]
002
TIFF (Multi/Single) *CTL
003
PDF *CTL
004
Other *CTL
