System SP Tables-8
SM Appendix 3-241 D158/D159/D160/D161/D170
Appendix:
Service
Program
Mode Tables
8741
RX PGS/Port (D158/D159)
These SPs count the number of pages received by the physical port used to
receive them.
001 PSTN-1 *CTL
[0to9999999 / 0 / 1]
002 PSTN-2 *CTL
003 PSTN-3 *CTL
004 ISDN (G3,G4) *CTL
005 Network *CTL
8781
Toner_Botol_Info.
(D158/D159)
*ENG
[0 to 9999999 / 0 / 1]
This SP displays the number of toner bottles used. The count is done based on
the equivalent of 1,000 pages per bottle.
8801
Toner Remain
(D158/D159)
*CTL
[0 to 100 / 0 / 1]
These SPs enable the display of the amount of toner remaining in steps of 10%.
Note: In actuality, the controller is capable of detecting changes in steps of 1%.
However, this SP relies on the detection data from the Engine (system), which
is limited to a detection resolution of 10% increments.
001 K
002 Y
003 M
004 C
Rev. 7/11/2014
⇒
