3. Clean the guide board of the paper feed unit.
4. After cleaning, restore the machine so that it resumes operation.
• For details about detaching and reattaching the parts, see the Replacement Guide
Cleaning the Paper Feed Rollers and Paper Feed Belt in the Interposer
Clean the paper feed belt and paper feed rollers in the interposer.
The procedure is explained using the interposer upper tray. The procedure is the same for the lower tray.
1. Remove the loaded paper.
2. Open the upper cover, and then detach the paper feed unit.
Pull it out slightly, release the metal shaft, and then detach it.
Cleaning the Paper Feed Path
85
