Ricoh Pro C5200s Operating Instructions Troubleshooting: Tcru/Oru

Blister-like White Spots
White spots 0.3–0.5 mm (0.01–0.02 inches) in diameter surrounded by denser spots (blister-like white
spots) appear.
CEZ602
Cause:
This may occur if a solid image is printed on coated paper, if a solid image is printed during duplex
printing, or if printing is done at low temperature.
Solution:
If blister-like white spots appear, carry out the procedure in page 64 "Insufficient Toner Fusing".
Mottling
Mottling occurs in solid-filled areas.
Normal
Color Loss
39

Ricoh Pro C5200s Specifications

General

Print Technology	Laser
Max Paper Size	330.2 x 487.7 mm
Monthly Duty Cycle	300, 000 pages
Print Speed	65 ppm
Resolution	1200 x 4800 dpi
Paper Input Capacity	8, 250 sheets
Paper Weight	52 to 360 gsm
Duplex Printing	Standard
Network Connectivity	Ethernet 10Base-T/100Base-TX/1000Base-T
Supported Media Sizes	A3, A4, A5, B4, B5
Supported Media Types	Plain, Recycled, Coated, Envelope
Warm-up Time	Less than 5 minutes
