Ricoh Pro C5200s - Multi-Folding Unit; Inaccurate Folding (Folding Deviation)

Multi-Folding Unit
Inaccurate Folding (Folding Deviation)
Cause:
Depending on paper hardness, inaccurate folds may result. This is referred to as folding deviation.
Solution:
Change the folding position by adjusting the position of the paper edge stopper for folding.
• For multi-sheet folding, change the folding position using the following settings:
Half Fold Position (Multi-sheet Fold)
Letter Fold-out Position 1 (Multi-sheet Fold)
Letter Fold-out Position 2 (Multi-sheet Fold)
Letter Fold-in Position 1 (Multi-sheet Fold)
Letter Fold-in Position 2 (Multi-sheet Fold)
• For single-sheet folding, change the folding position using the following settings:
Adjust Z-fold Position 1
Adjust Z-fold Position 2
Half Fold Position: Single-sheet Fold
Letter Fold-out Posn 1: Single-sheet Fld
Letter Fold-out Posn 2: Single-sheet Fld
Letter Fold-in Posn 1: Single-sheet Fold
Letter Fold-in Posn 2: Single-sheet Fold
Double Parallel Fold Position 1
Double Parallel Fold Position 2
Adjust Gate Fold Position 1
Adjust Gate Fold Position 2
Adjust Gate Fold Position 3
• For details about specifying settings in the [Adjustment Settings for Skilled Operators] menu, see the
Adjustment Item Menu Guide.
5. Post-Processing Option Troubleshooting
96
