Ricoh Pro C5200s Operating Instructions Troubleshooting: Tcru/Oru

Cause:
When a particularly dense image is printed, the paper feed rollers may become soiled with toner and
the paper edges may in turn be soiled by the toner on the paper feed rollers.
Solution:
For details about cleaning the paper feed rollers, see page 84 "Cleaning the Paper Feed Path".
Paper Edges Are Stained (3) (Finisher SR5070 / Booklet Finisher SR5080)
Cause:
When Z-folded paper is punched, the paper edges may become stained.
Solution:
1. In the [Finishing: Finisher] group on the [Adjustment Settings for Skilled Operators] menu,
set [Z-fold Skew Correction] to [On].
2. Print the image. Has the problem been resolved?
Yes Finished!
No Set [Correct Z-fold Skew] to "-6.0".
3. Print the image. Has the problem been resolved?
Yes Finished!
No Contact your service representative.
When Z-folded Paper is Punched, Jam Code J471Appears (Finisher SR5070 /
Booklet Finisher SR5080)
Cause:
When Z-folded paper is punched, the center of the paper may be arched and the paper may be
creased or bent at corners, resulting in a paper jam.
5. Post-Processing Option Troubleshooting
94

Ricoh Pro C5200s Specifications

General

Print Technology	Laser
Max Paper Size	330.2 x 487.7 mm
Monthly Duty Cycle	300, 000 pages
Print Speed	65 ppm
Resolution	1200 x 4800 dpi
Paper Input Capacity	8, 250 sheets
Paper Weight	52 to 360 gsm
Duplex Printing	Standard
Network Connectivity	Ethernet 10Base-T/100Base-TX/1000Base-T
Supported Media Sizes	A3, A4, A5, B4, B5
Supported Media Types	Plain, Recycled, Coated, Envelope
Warm-up Time	Less than 5 minutes
