RIGOL 2 Command System
2-84 MSO2000A/DS2000A Programming Guide
:CURSor:TRACk:CAX
:CURSor:TRACk:CBX
Syntax
:CURSor:TRACk:CAX <ax>
:CURSor:TRACk:CAX?
:CURSor:TRACk:CBX <bx>
:CURSor:TRACk:CBX?
Description
Set or query the horizontal position of cursor A or cursor B in track cursor measurement.
Parameter
Name Type Range Default
<ax> Integer 0 to 699 150
Explanation
The horizontal and vertical positions of the cursor are defined by the pixel coordinate of the screen. The
pixel coordinate of the screen ranges from (0,0) to (700,400). Wherein, (0,0) is located at the left top
corner of the screen and (700,400) is located at the right bottom corner of the screen. The horizontal
pixel range is from 0 to 699.
Return Format
The query returns an integer between 0 and 699.
:CURSor:TRACk:CAY?
:CURSor:TRACk:CBY?
Syntax
:CURSor:TRACk:CAY?
:CURSor:TRACk:CBY?
Description
Query the vertical position of cursor A or cursor B in track cursor measurement.
Return Format
The query returns an integer.
