Rigol MSO2000A Series Programming Guide

RIGOL 2 Command System
2-260 MSO2000A/DS2000A Programming Guide
[:TRACe<n>]:DATA:DAC16
Syntax
[:TRACe<n>]:DATA:DAC16 volatile,<flag>,<binary_block_data>
Description
Download binary data block into the volatile memory of the built-in signal source.
Parameter
Name Type Range Default
<n> Discrete {1|2} 1
<flag> Discrete {END} --
<binary_block_data> Refer to the Explanation
Explanation
 This command consists of two parts: the command string ([:TRACe<n>]:DATA:DAC16
volatile,<flag>) and the bianry data (<binary_block_data>).
 <flag> denotes the data transmission status and can only be set to END which denotes this data
packet is the last one and the data transmission finishes.
 <binary_block_data> denotes the binary data to be downloaded. The range is from 0000 to 3FFF.
The data length is from 2pts (4Bytes) to 16kpts (32kBytes). The binary data block starts with #. For
example, send the command :DATA:DAC16 VOLATILE,END,#532768 binary data
The number “5” behind # denotes that the data length information (32768) occupies 5 characters.
32768 denotes the number of bytes of the binary data. As each waveform point occupies two
bytes, the number of bytes must be an even number.
 When the data transmission complte denoter END is recieved, the instrument switches to arbitrary
waveform output automatically.
