RIGOL 2 Command System
2-228 MSO2000A/DS2000A Programming Guide
[:SOURce<n>]:VOLTage[:LEVel][:IMMediate][:AMPLitude]
Syntax
[:SOURce<n>]:VOLTage[:LEVel][:IMMediate][:AMPLitude] {<amplitude>|MINimum|MAXimum}
[:SOURce<n>]:VOLTage[:LEVel][:IMMediate][:AMPLitude]? [MINimum|MAXimum]
Description
Set or query the amplitude of the waveform currently selected. The default unit is Vpp.
Parameter
Name Type Range Default
<amplitude> Real
HighZ: 20mVpp to 5Vpp
50Ω: 10mVpp to 2.5Vpp
5Vpp
<n> Discrete {1|2} 1
Explanation
You can use
:OUTPut[<n>]:IMPedance command to set the output impedance of the signal source.
Return Format
The query returns the current amplitude in scientific notation.
