2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-279
:TRIGger:IIC
 :TRIGger:IIC:ADDRess
 :TRIGger:IIC:AWIDth
 :TRIGger:IIC:CLEVel
 :TRIGger:IIC:DLEVel
 :TRIGger:IIC:DATA
 :TRIGger:IIC:DIRection
 :TRIGger:IIC:SCL
 :TRIGger:IIC:SDA
 :TRIGger:IIC:WHEN
:TRIGger:IIC:ADDRess
Syntax
:TRIGger:IIC:ADDRess <adr>
:TRIGger:IIC:ADDRess?
Description
Set or query the address value in I2C trigger when the trigger condition is Address or A&D.
Parameter
Name Type Range Default
<adr> Integer 0 to 2
n
–1 1
Note: In the expression 2
n
-1, n is the current address bits (refer to the :TRIGger:IIC:AWIDth command) and can be
7, 8 or 10. Therefore, the range of <adr> can be 0 to 127, 0 to 255 or 0 to 1023.
Explanation
To set the I2C trigger condition, refer to the
:TRIGger:IIC:WHEN command.
Return Format
The query returns an integer.
