Rigol MSO2000A Series Programming Guide

RIGOL 2 Command System
2-290 MSO2000A/DS2000A Programming Guide
:TRIGger:PULSe
 :TRIGger:PULSe:LEVel
 :TRIGger:PULSe:LWIDth
 :TRIGger:PULSe:SOURce
 :TRIGger:PULSe:UWIDth
 :TRIGger:PULSe:WHEN
:TRIGger:PULSe:LEVel
Syntax
:TRIGger:PULSe:LEVel <level>
:TRIGger:PULSe:LEVel?
Description
Set or query the trigger level in pulse trigger. The unit is the same as the current amplitude unit.
Parameter
Name Type Range Default
<level> Real
When the trigger source is CHANnel1 or CHANnel2:
-5×VerticalScale–OFFSet to +5×VerticalScale–OFFSet
When the trigger source is any of D0-D15: -20V to 20V
When the trigger source is EXT: -4V to 4V
0
Note: For the VerticalScale, refer to the :CHANnel<n>:SCALe command. For the OFFSet, refer to
the
:CHANnel<n>:OFFSet command.
Return Format
The query returns the trigger level in scientific notation.
