Rigol MSO2000A Series Programming Guide

RIGOL 2 Command System
2-160 MSO2000A/DS2000A Programming Guide
:MEASure:NWIDth
Syntax 1
:MEASure:NWIDth <chan>
Description 1
Enable the negative pulse width measurement function of the specified channel.
Syntax 2
:MEASure:NWIDth? <chan>
Description 2
Enable the negative pulse width measurement function of the specified channel and return the
measurement result (the unit is s).
Parameter
Name Type Range Default
<chan> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D11|
D12|D13|D14|D15|CHANnel1|CHANnel2|MATH}
--
Return Format
The query returns the measurement result in scientific notation.
Example
:MEASure:NWIDth CHANnel1
:MEASure:NWIDth? CHANnel1
You can use the following commands to query the statistic maximum, minimum, current value, average
and standard deviation of the negative pulse width measurement values of the specified channel
waveform. Sending the following commands will enable the statistic function automatically.
 :MEASure:NWIDth:SMAXimum?
 :MEASure:NWIDth:SMINimum?
 :MEASure:NWIDth:SCURrent?
 :MEASure:NWIDth:SAVerage?
 :MEASure:NWIDth:SDEViation?
