Page #34 background image
RIGOL 2 Command System
2-18 MSO2000A/DS2000A Programming Guide
:BUS<n>:DATA?
Syntax
:BUS<n>:DATA?
Description
Read the decoding event table data.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
Return Format
The query returns the decoding event table data in the following format.
#9000000141RS232
Time,TX,TX ERR,
-6.1352322E-03,*,,
-4.0554402E-03,R,,
-1.9756482E-03,I,,
1.0414385E-04,G,,
2.1839839E-03,O,,
4.2637759E-03,L,,
Wherein, #9000000141 is the TMC data block header following which is the data in the event table. The
figure behind #9 denotes the number of bytes of the effective data. RS232 denotes the decoding mode (it
can also be Parallel, I2C, SPI or CAN). The data are separated by commas and will be displayed in
different lines automatically according to the lines in the decoding table. The data value is related to the
specified format (
:BUS<n>:FORMat).
Note: You can save the data (except the TMC data block header and the decoding type; for example,
#9000000141RS232) as a *.csv file and view the data in table form.
