Rigol MSO2000A Series Programming Guide

RIGOL
II MSO2000A/DS2000A Programming Guide
Document Overview
This manual guides users to control RIGOL MSO2000A/DS2000A series digital oscilloscope remotely by
programming using SCPI commands through the remote interface. MSO2000A/DS2000A can build
communication with a PC through the USB, LAN or GPIB (with the USB-GPIB interface converter provided
by RIGOL) interface.
Main Topics in this Manual:
 SCPI Overview
 Command System
 Programming Demos
Content Conventions in this Manual:
MSO2000A/DS2000A series includes the following models. Unless otherwise noted, this manual takes
MSO2302A-S as an example to illustrate the functions and using method of the command system of
MSO2000A/DS2000A series.
Model
Analog
Bandwidth
Number of
Analog
Channels
Number of
Signal Source
Channels
Number of
Digital
Channels
MSO2072A 70MHz 2 -- 16
MSO2072A-S 70MHz 2 2 16
MSO2102A 100MHz 2 -- 16
MSO2102A-S 100MHz 2 2 16
MSO2202A 200MHz 2 -- 16
MSO2202A-S 200MHz 2 2 16
MSO2302A 300MHz 2 -- 16
MSO2302A-S 300MHz 2 2 16
DS2072A 70MHz 2 -- --
DS2072A-S 70MHz 2 2 --
DS2102A 100MHz 2 -- --
DS2102A-S 100MHz 2 2 --
DS2202A 200MHz 2 -- --
DS2202A-S 200MHz 2 2 --
DS2302A 300MHz 2 -- --
DS2302A-S 300MHz 2 2 --

Rigol MSO2000A Series Specifications

General

Brand	Rigol
Model	MSO2000A Series
Category	Test Equipment
Language	English
