RIGOL 2 Command System
2-158 MSO2000A/DS2000A Programming Guide
:MEASure:NDUTy
Syntax 1
:MEASure:NDUTy <chan>
Description 1
Enable the negative duty cycle measurement function of the specified channel.
Syntax 2
:MEASure:NDUTy? <chan>
Description 2
Enable the negative duty cycle measurement function of the specified channel and return the
measurement result.
Parameter
Name Type Range Default
<chan> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D11|
D12|D13|D14|D15|CHANnel1|CHANnel2|MATH}
--
Return Format
The query returns the measurement result in scientific notation.
Example
:MEASure:NDUTy CHANnel1
:MEASure:NDUTy? CHANnel1
You can use the following commands to query the statistic maximum, minimum, current value, average
and standard deviation of the negative duty cycle measurement values of the specified channel waveform.
Sending the following commands will enable the statistic function automatically.
 :MEASure:NDUTy:SMAXimum?
 :MEASure:NDUTy:SMINimum?
 :MEASure:NDUTy:SCURrent?
 :MEASure:NDUTy:SAVerage?
 :MEASure:NDUTy:SDEViation?
