RIGOL 2 Command System
2-336 MSO2000A/DS2000A Programming Guide
:WAVeform:XORigin?
Syntax
:WAVeform:XORigin?
Description
Query the time from the trigger point to the reference time (refer to the
:WAVeform:SOURce command)
of the specified source (refer to the
:WAVeform:XREFerence? command) in X direction. The unit is s.
Explanation
The unit is related to the current channel source. When the channel source is CHANnel1, CHANnel2 or D0
to D15, the unit is s. When the channel source is MATH with FFT operation or the channel source is FFT,
the unit is Hz.
Return Format
The query returns the time value in scientific notation.
:WAVeform:XREFerence?
Syntax
:WAVeform:XREFerence?
Description
Query the reference time of the specified source (refer to the
:WAVeform:SOURce command) in X
direction. The unit is s.
Return Format
The query returns 0 (namely the first waveform point on the screen or in the internal memory).
:WAVeform:YINCrement?
Syntax
:WAVeform:YINCrement?
Description
Query the voltage value per unit of the specified source (refer to the
:WAVeform:SOURce command) in Y
direction. The unit is the same with the unit of the signal source.
Explanation
YINCrement=VerticalScale/25
Return Format
The query returns the voltage value in scientific notation.
