2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-103
:FUNCtion:WANalyze
 :FUNCtion:WANalyze:MODE
 :FUNCtion:WANalyze:SOURce
 :FUNCtion:WANalyze:FCURrent
 :FUNCtion:WANalyze:TDISp
 :FUNCtion:WANalyze:SETup:SSTart
 :FUNCtion:WANalyze:SETup:SSENd
 :FUNCtion:WANalyze:SETup:SFRame
 :FUNCtion:WANalyze:SETup:EFRame
 :FUNCtion:WANalyze:SETup:THReshold
 :FUNCtion:WANalyze:SETup:XMASk
 :FUNCtion:WANalyze:SETup:YMASk
 :FUNCtion:WANalyze:STEMplate
 :FUNCtion:WANalyze:CMASk
 :FUNCtion:WANalyze:STARt
 :FUNCtion:WANalyze:CANCel
 :FUNCtion:WANalyze:PREVious
 :FUNCtion:WANalyze:NEXT
 :FUNCtion:WANalyze:EFCount?
 :FUNCtion:WANalyze:ECURrent
 :FUNCtion:WANalyze:ECDiff?
:FUNCtion:WANalyze:MODE
Syntax
:FUNCtion:WANalyze:MODE <mode>
:FUNCtion:WANalyze:MODE?
Description
Set or query the mode of waveform analysis.
Parameter
Name Type Range Default
<mode> Discrete {TRACe|MASK} TRACe
Explanation
 TRACe: trace mode. Analyze on the basis of the template selected by users.
 MASK: pass/fail test. Analyze on the basis of the pass/fail test mask created by users.
Return Format
The query returns TRAC or MASK.
