:FUNCtion:WANalyze:SETup:XMASk
:FUNCtion:WANalyze:SETup:YMASk
Syntax
:FUNCtion:WANalyze:SETup:XMASk <x>
:FUNCtion:WANalyze:SETup:XMASk?
:FUNCtion:WANalyze:SETup:YMASk <y>
:FUNCtion:WANalyze:SETup:YMASk?
Description
Set or query the horizontal or vertical adjustment parameter in analysis based on the pass/fail mask and
the unit is div.
Parameter
Name Type Range Default
<x> Real 0.02 to 4, the step is 0.02 0.24
<y> Real 0.04 to 5.12, the step is 0.04 0.48
Return Format
The query returns the current horizontal or vertical adjustment parameter in scientific notation.
:FUNCtion:WANalyze:STEMplate
Syntax
:FUNCtion:WANalyze:STEMplate
Description
Set the waveform analysis template when the analysis mode is trace.
Explanation
After the analysis starts, the oscilloscope compares each frame of data measured with the data in the
template to determine whether error frame exists according to the threshold set.
