RIGOL 2 Command System
2-108 MSO2000A/DS2000A Programming Guide
:FUNCtion:WANalyze:CMASk
Syntax
:FUNCtion:WANalyze:CMASk
Description
Apply the mask currently created.
Explanation
 For the setting of the horizontal adjustment parameter, refer to
the
:FUNCtion:WANalyze:SETup:XMASk command.
 For the setting of the vertical adjustment parameter, refer to the
:FUNCtion:WANalyze:SETup:YMASk
command.
:FUNCtion:WANalyze:STARt
Syntax
:FUNCtion:WANalyze:STARt
Description
Start the waveform analysis.
Explanation
During the analysis process, the progress bar is displayed and the parameters cannot be modified. After
the analysis finishes, the analysis results of “Error Frames”, “Current Error” and “CurFrame Diff” are
displayed; at the same time, the first error frame is located.
:FUNCtion:WANalyze:CANCel
Syntax
:FUNCtion:WANalyze:CANCel
Description
Give up the waveform analysis.
Explanation
After stopping the waveform analysis, you can use the
:FUNCtion:WANalyze:STARt command to restart
the waveform analysis.
