Rigol MSO2000A Series Programming Guide

2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-273
:TRIGger:DURATion (Option)
 :TRIGger:DURATion:SOURce
 :TRIGger:DURATion:TLOWer
 :TRIGger:DURATion:TUPPer
 :TRIGger:DURATion:TYPe
 :TRIGger:DURAtion:WHEN
:TRIGger:DURATion:SOURce
Syntax
:TRIGger:DURATion:SOURce <source>
:TRIGger:DURATion:SOURce?
Description
Set or query the trigger source of duration trigger.
Parameter
Name Type Range Default
<source> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|
D11|D12|D13|D14|D15|CHANnel1|CHANnel2}
CHANnel1
Return Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14, D15, CHAN1 or
CHAN2.
:TRIGger:DURATion:TLOWer
Syntax
:TRIGger:DURATion:TLOWer <tlower>
:TRIGger:DURATion:TLOWer?
Description
Set or query the lower limit of the duration time in duration trigger. The unit is s.
Parameter
Name Type Range Default
<tlower> Real
When the trigger condition is >: 2ns to 4s
When the trigger condition is <>: 2ns to 3.99s
1us
Return Format
The query returns the lower limit of the duration time in scientific notation.
