Rigol MSO2000A Series Programming Guide

RIGOL 2 Command System
2-254 MSO2000A/DS2000A Programming Guide
:TIMebase:DELay:OFFSet
Syntax
:TIMebase:DELay:OFFSet <offset>
:TIMebase:DELay:OFFSet?
Description
Set or query the horizontal position of the delayed sweep and the unit is s.
Parameter
Name Type Range Default
<offset> Real -(LeftTime-DelayRange/2) to (RightTime-DelayRange/2) 0
Note:
LeftTime=7×MainScale-MainOffset. For the MainScale, refer to the
:TIMebase[:MAIN]:SCALe command.
RightTime=7×MainScale+MainOffset. For the MainOffset, refer to the
:TIMebase[:MAIN]:OFFSet command.
DelayRange=14×DelayScale. For the DelayScale, refer to the
:TIMebase:DELay:SCALe command.
Return Format
The query returns the horizontal position in scientific notation.
:TIMebase:DELay:SCALe
Syntax
:TIMebase:DELay:SCALe <scale_value>
:TIMebase:DELay:SCALe?
Description
Set or query the delayed sweep time base and the unit is s/div.
Parameter
Name Type Range Default
<scale_value> Real
(1×50/real-time sample rate)×1/40 to the current main
time base
500ns/div
Note: For the main time base, refer to the :TIMebase[:MAIN]:SCALe command.
Return Format
The query returns the delayed sweep time base in scientific notation.
