Rigol MSO2000A Series Programming Guide

RIGOL 2 Command System
2-180 MSO2000A/DS2000A Programming Guide
:MEASure:R2FPhase
Syntax 1
:MEASure:R2FPhase <chanA>,<chanB>
Description 1
Enable the phase deviation measurement function (rising edge-falling edge) between the two specified
channels.
Syntax 2
:MEASure:R2FPhase? <chanA>,<chanB>
Description 2
Enable the phase deviation measurement function (rising edge-falling edge) between the two specified
channels and return the measurement result (the unit is degree).
Parameter
Name Type Range Default
<chanA> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D11|
D12|D13|D14|D15|CHANnel1|CHANnel2}
--
<chanB> Discrete
When <chanA> is D0-D15:
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D11|D12|D13|D14|
D15}
When <chanA> is CHANnel1 or CHANnel2:
{CHANnel1|CHANnel2}
--
Return Format
The query returns the measurement result in scientific notation.
Example
:MEASure:R2FPhase CHANnel1,CHANnel2
:MEASure:R2FPhase? CHANnel1,CHANnel2
You can use the following commands to query the statistic maximum, minimum, current value, average
and standard deviation of the phase deviation measurement (rising edge-falling edge) results. Sending
the following commands will enable the statistic function automatically.
 :MEASure:R2FPhase:SMAXimum?
 :MEASure:R2FPhase:SMINimum?
 :MEASure:R2FPhase:SCURrent?
 :MEASure:R2FPhase:SAVerage?
 :MEASure:R2FPhase:SDEViation?
