RIGOL 2 Command System
2-138 MSO2000A/DS2000A Programming Guide
:MEASure:ADISplay
Syntax
:MEASure:ADISplay <bool>
:MEASure:ADISplay?
Description
Enable or disable all measurement; or query the current status of all measurement.
Parameter
Name Type Range Default
<bool> Bool {{0|OFF}|{1|ON}} 0|OFF
Explanation
 All measurement can measure all the time and voltage parameters of the current measurement
source. Each measurement source has 21 measurement parameters and you can measure the three
measurement sources (CH1, CH2 and MATH) at the same time.
 11 voltage measurement items: maximum, minimum, peak-peak, top, bottom, amplitude, average,
RMS, period RMS, overshoot and preshoot.
 8 time measurement items: period, frequency, rise time, fall time, positive pulse width, negative
pulse width, positive duty cycle and negative duty cycle.
 2 other measurement items: area and period area.
Return Format
The query returns 0 or 1.
:MEASure:AMSource
Syntax
:MEASure:AMSource <chan>[,<chan>[,<chan>]]
:MEASure:AMSource?
Description
Set or query the signal source of the all measurement parameters.
Parameter
Name Type Range Default
<chan> Discrete {CHANnel1|CHANnel2|MATH} CHANnel1
Return Format
The query returns CHAN1, CHAN2 or MATH. Multiple signal sources are separated by commas.
