Rigol MSO2000A Series Programming Guide

2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-339
:WAVeform:STOP
Syntax
:WAVeform:STOP <sta>
:WAVeform:STOP?
Description
Set or query the stop position of internal memory waveform reading.
Parameter
Name Type Range Default
<sta> Integer
NORMal: 1 to 1400
MAX: 1 to the number of effective point currently on
the screen
RAW: 1 to the current maximum memory depth
1400
Explanation
 For the memory depth, refer to the
:ACQuire:MDEPth command.
 The range of the start position is limited by the current waveform reading mode (refer to
the
:WAVeform:MODE command).
Return Format
The query returns an integer.
:WAVeform:BEGin
Syntax
:WAVeform:BEGin
Description
Enable the waveform reading.
:WAVeform:END
Syntax
:WAVeform:END
Description
Stop the waveform reading.
